HIPOT Tester 19071/19072/19073 User’s Manual
5-24
5.7 Flow Diagram
1. Confirm if all of Slaves’ communication is normal or not:
Power Up
Set x to 1
(x is the slave
address that
will be
checked)
Send "Display
Address" command
(command code:
0x20) for slave x
Return OK
message?
x add 1
All slaves finished
Standby
Yes
Yes
No
Alarm
No
