Panel Description
CURRENT M.: (3302 only)
To select whether the output voltage is shown on MEAS. Display of LCR testing. The value
is being set on "OFF". The selector is "ON/OFF". The procedure is to move the cursor to
the right of the CURRENT M. by pressing and adjust it by pressing [ON] and [OFF].
SOUNDS MODE: (3302 only)
To select whether the buzzer is working for good (PASS) or no-good (NG) product under high
or low limit judgment on MEAS. DISPLAY of LCR testing. The value is being set on
"PASS". The selector is "PASS/NG". The procedure is to move the cursor to the right of
the SOUNDS MODE by pressing and adjust it by pressing [PASS] and [NG].
ALARM MODE: (3302 only)
To select whether the alarm is warming for SHOT or LEVEL under high or low limit
judgment on MEAS. DISPLAY of LCR testing. The value is being set on "SHORT". The
selector is "SHOT/LEVEL". The procedure is to move the cursor to the right of the
ALARM MODE by pressing and adjust it by pressing [SHOT] and [LEV.].
DEVIATION:
To select whether the equivalent error minus function is switch on between the unit and other
testers. The value is being set on "200%". The selector is "5%
〜
EVER". The procedure
is to move the cursor to the right of the DEVIATION? by pressing and adjust it by
pressing [ ] and [ ].
Note: Ex. set 100%, as test value/Actual value >2 x Actual value, it will give up
DEVIATION action.
CONST Rsour:
In LCR measure condition, the output impedance of test terminal is fixed. The application
of this function is suitable for the DUT which the variable of measurement is too large. So
use this function will not let the measurement variable influence accuracy. The initial value
is "OFF". The range of control are OFF, 320X, 106X, 1072 four choices. The control
method is to select the keys beside the Cursor, move it from the block to Const and Rsour.
press selection key to set Const mode in LCD right side.
USER PS. WORD:
To select whether the user password needed to key in after the unit is switch on or the user
desire to alter the setting parameter. The value is being set on "OFF" The selector is
"ON/OFF". The procedure is to move the cursor to the right of the USER PS. WORD by
pressing and adjust it by pressing [ON] and [OFF].
DELAY TIME:
To choose after the tome needed from delay to next test after DCR testing. After DCR
testing, the emerge will be remained in the transformer, it maybe influence the next test.
So this delay function is needed to eliminate. The range of control is 00 to 9999. Each
resolution is 10ms.
