Regenerative Charge/Discharge Tester 69225/69212 Series User’s Manual
1-2
WIR_LOS
ABS(Vlocal-Vrmt)
>
Vmax*5% +
ISET_MAX*0.03
Wire loss too large (or RMT wire off)
SYS_OCP
Hardware protection
Hardware pulse by pulse overcurrent
protection.
SYS_OTP
Hardware protection
692 inner temperature over high
SYS_FAN
Hardware protection
692 inner fan blocked
AUX_ERR
Hardware protection
Auxiliary power error is detected.
CAL_ERR
Hardware protection
Calibration value error (uncalibrated
included)
SW_OVP
Software protection (Effective Program
Mode)
Vlocal
≥
(OVP_SET + Vmax*5%) +
ISET_MAX*0.03
Local voltage is higher than output
setting (user-defined)
SW_UVP
Software protection (Effective Program
Mode)
Vlocal
≤
(UVP_SET - Vmax*5%) -
ISET_MAX*0.03
Local voltage is lower than output
setting (user-defined)
Note
1. DC Bus rated: 420V
2. VSET_MAX / ISET_MAX: Refer the section for specification.
3. Protections above are for single channel.
1.2.3 Output
 Output connector is located at rear panel. Each output channel consists of upper
charge/discharge output and lower discharge output.
 Manual operation needs to via Chroma 69200-x controller (optional equipment) to
proceed.
 Remote operation needs to via Chroma 69200-x controller (optional equipment) to
coordinate with Ethernet card (optional equipment) and IPC via software to do remote
control.
 Output protection detection (OUT_RVS, OUT_OVP, OUT_OCP, BAT_RVS, BAT_OVP,
WIR_LOS, etc.)
1.2.4 Input
 Input connector is located at rear panel, each tester has one input connector which
provides 420V to do dual power transmission from A691101.
 Input protection detection (BUS_OVP, BUS_UVP, etc.)
1.2.5 Measurement and Edit
 System needs to via Chroma 69200-x controller (optional equipment) to coordinate with
software to perform outputting current/voltage/power… etc. measurements.
 System needs to via Chroma 69200-x controller (optional equipment) to coordinate with
software to perform outputting Program, Waveform… etc. edits.
