Cavity Cartridge Fuse Description
F83
20 Amp Blue TT Park Lights — If Equipped
30 Amp Pink
Headlamp Washer Pump —
If Equipped
F94 40 Amp Green ESC Motor Pump
F99 30 Amp Pink
Electrical Brake Module/Trailer
Tow — If Equipped
Circuit Breakers
CB1 25 Amp Power Seats (Driver)
CB2 25 Amp * Power Seats (Pass)
CB3 25 Amp
FRT PWR Window
W/O Door Nodes +
RR PWR Window
Lockout
ADDING FUEL
There is no fuel filler cap. Two flapper doors inside the pipe seal the system.
WARNING!
• Never have any smoking materials lit in or near the vehicle when the fuel door is open or the
tank is being filled.
• Never add fuel when the engine is running. This is in violation of most state and federal fire
regulations and may cause the MIL to turn on.
• A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.
You could be burned. Always place gas containers on the ground while filling.
CAUTION!
To avoid fuel spillage and overfilling, do not “top off” the fuel tank after filling.
1. Put the vehicle in park and switch the ignition off.
2. Push the center-rear edge of the fuel filler door (3 o'clock position) and release to open.
3. Insert the fuel nozzle fully into the filler pipe, the nozzle opens and holds both flapper doors
while refueling.
4. When the fuel nozzle “clicks” or shuts off, the fuel tank is full.
5. Keep the nozzle in the filler for five seconds after nozzle clicks to allow fuel to drain from the
nozzle.
6. Remove the fuel filler nozzle.
