1-2 Overview
3916 Service Delivery Switch Hardware Installation and Start-up Manual
009-3226-001 Standard Revision E
Copyright
©
2013-2015 Ciena
®
Corporation July 2015
The 3916 can be deployed in Central Offices (CO), customer premises (CPE)
and other environmentally controlled telecommunications spaces. The 3916
is part of a group of products designed to address the connectivity
requirements of different sites and services. In addition, Ciena offers SDS and
SAS units designed for both outside plant and interior applications. A full
description of the various products in the portfolio, including a hardware
overview of the 3916
, is contained in 39XX/51XX Product Fundamentals.
The SDS units are designed to work with other Ciena products to deliver
complete, integrated service offerings from a single provider or multiple
providers. The SDS devices incorporate advanced QoS capabilities, flexibility
through pluggable optics, superior multicast control, manageability, and a
small form factor chassis to present the industry’s leading fiber-to-the-building
solution.
Table 1-2 provides an overview of the interfaces available on the 3916 switch.
In addition, the 3916 has the following physical characteristics:
• Single integrated front fixed AC or DC power supply or dual integrated
front fixed AC power supplies
• 1 RU form factor
Table 1-1
3916 System Summary
System Part Number Power System Chassis Size Airflow
3916 AC Standard 170-3916-900 Single AC Standard Side to Side
(right to left)
3916 Dual AC Standard 170-3916-902 Dual AC Standard Side to Side
(right to left)
3916 DC Standard 170-3916-901 Single DC Standard Side to Side
(right to left)
3916 AC Mini 170-3916-904 Single AC Mini Front to back
3916 Dual AC Mini 170-3916-906 Dual AC Mini Front to back
Note: For more information, see 39XX/51XX Product Fundamentals.
