Overview 1-3
3916 Service Delivery Switch Hardware Installation and Start-up Manual
009-3226-001 Standard Revision E
Copyright
©
2013-2015 Ciena
®
Corporation July 2015
Figure 1-1 on page 1-4 shows the 3916 standard chassis. Figure 1-2 on page
1-4 shows the 3916 mini chassis.
Table 1-2
3916 interface summary
Port type Number of
ports
Description
NNI 2 100/1000 Mbps ports with SFP connectors. These are ports 3 and 4.
Copper SFPs installed in these ports support 10/100/1000 Mbps.
NNI 2 1000 Mbps ports with SFP connectors. These are ports 5 and 6.
Copper SFPs installed in these ports support 1G.
UNI 2 10/100/1000 Mbps combo RJ-45/SFP ports. The SFPs support both 100
Mbps and 1000 Mbps speeds. These are ports 1 and 2.
The combo ports have both a copper and an optical version of the same
port. Both ports can be cabled, however only one of the pair of copper/
optic ports will be active at any time. The combo ports are controlled
through the software.
Copper SFPs installed in these ports support 1G.
Console 1 Serial EIA-561 (RJ-45) port
Note 1: For the combo ports, only one of the two ports will be active. Either the copper or the optical
port will be active.
Note 2: Only Ciena approved SFPs can be used with the 3916. For more information see Packet
Networking Transceivers Reference (009-2011-602).
