CIMLINE C1 - Material Tank Capacity

25
Material Tank Capacity
MATERIAL CAPACITY
(Tank cutaway)
MATERIAL VAT
AIR
OIL
C1
6.8 GALLONS PER INCH
Material Depth
Gallons Material in Tank
2" 13.6
4" 27.18
6" 40.78
8" 54.37
10" 67.96
12" 81.56
14" 95.15
16" 108.74
18" 122.34
20" 135.93
22" 149.52
The amount of material can be calculated by measure the depth of material in the tank.
INSULATION
