27
Fluid and Components Specifications
Only the oil specified or equal may be used in this system.
(Always check your local and state regulations before disposal).
NOTE: A dipstick (A) is provided for checking heat transfer oil level when cold.
This is a petroleum based product. CIMLINE recommends that you do not mix oil
brands. Mixing any oils (Engine oil, transmission fluid, etc.) adversely affects each
manufacturers formula.
C1
Hydraulic Reserve Capacity 30 Gallons (114L)
Hydraulic Oil Type Conoco MV32 or equiv
Diesel Fuel Capacity 30 Gallons (114L)
Diesel Fuel Type ASTM D975 No.2
Heat Transfer Oil Capacity 21 Gal. (80L)
Heat Transfer Oil Type See Specs. On Previous page.
Agitation Drive Relief Setting 1100 PSI (76 bar)
Material Pump Drive Relief Setting 800 PSI (55 bar)
Material Pump Maximum Output
Pressure
125 PSI (8.62 bar)
NOTICE
COLD OIL LEVEL - OIL MUST BE BETWEEN
MARKING WHEN COLD
(A)
