46
Sealing Wand PN 407861
# PART # DESCRIPTION QTY.
# PART # DESCRIPTION QTY.
1 429945 STUD 1
16 130323 SWITCH - MOMENTARY 2
2 427557 CLUTCH LEVER 1
17 130224 BOOT, SWITCH 2
3 427358 ROD 1
18 130155 CLEVIS KIT-.25-28 X .25 1
4 427116 SPRING GUARD 1
19 120560 WAND VALVE .75 IN 1
5 426987 SPACER 1
20 120412 PIPE-NIPPLE-CLOSE-.75 1
6 407872 SUB HANDLE 1
21 111725 THRUST WASHER 2
7 407863 WAND SUB -WELD 1
22 100275 COTTER PIN .09 X .75 1
8 407862 HANDLE 1
23 100207 .25 NUT 2
9 407232 SWIVEL TIP 1
24 100169 NUT-PLASTIC LOCK .38 3
10 403905 VALVE LEVER 1
25 100126 WASHER-FLAT .38 2
11 170635 SWIVEL 1
26 100125 WASHER-FLAT .31 1
12 155297 SPRING 1
27 100092 WASHER-SPLITLOCK .31 1
13 155272 SLEEVE W/ LINK 1
28 100022 HHCS .38X2.5 1
14 130580 HARNESS, WAND 1
29 100017 HHCS .38 X 1.25 2
15 130324 LOCKNUT - 5/8-32 BRASS 2
30 100009 HHCS .31 X 1.75 1
To Next Page
