CIMLINE C1 - Replacement Labels

59
Replacement Labels
Inspect your labels and replace any damaged. Contact your dealer to order replacement labels
PN: 161441
PN: 161808
*WEAR GLOVES WITH WRISTLETS
DO NOT WEAR OPEN WRIST GLOVES.
*WEAR LONG PANTS
*WEAR LONG SLEEVE SHIRT WITH SLEEVES
ROLLED DOWN AND BUTTONED.
*WEAR HIGH TOP SAFETY SHOES.
*WEAR FACE MASK WHEN LOADING MATERIAL
*NEVER LEAVE MACHINE
UNATTENDED WHILE RUNNING.
*KEEP MATERIAL DOOR CLOSED
EXCEPT WHEN LOADING.
*STAND CLEAR OF OUTLET SPIGOT
WHEN OPENING.
*NEVER STAND ON THE MACHINE.
*STAY CLEAR OF EXHAUST AREA.
WARNING
!
FAILURE TO OBSERVE THE SAFETY
RULES COULD RESULT IN
SERIOUR BODILY INJURY OR DEATH.
HOT MATERIAL
RESPIRATOR
EYE OR FACE
PROTECTION
HEAD
PROTECTION
TO PREVENT
SERIOUS INJURY
HEARING
PROTECTION
PROTECCION
PARA LA CABEZA
MASCARA
RESPIRATORIA
PROTECCION PARA
LOS OJOS y LA CARA
PARA PREVENIR UN
ACCIDENTE SERIO
PROTECCION
PARA LOS OIDOS
ALERTA
!
READ OWNER'S
MANUAL BEFORE
OPERATING
Operators Manual
Please Read and Understand
Entire Manual Before Operating Eqiupment
STAY CLEAR OF ACTUATOR
WHILE ENGINE IS RUNNING
MANUFACTURER RECOMMENDS
ASTM D975 NO. 2-D S15
(THE GENERAL AUTOMOTIVE DIESEL ENGINE
ALL-PURPOSE FUEL OIL) OR EQUIVALENT
WHICH FULLY MEETS THE ABOVE REQUIREMENTS.
DIESEL FUEL ONLY
CHECK HYDRAULIC OIL LEVEL BEFORE STARTING:
HYDRAULIC OIL
1. CHECK SIGHT GAUGE TO VERIFY FLUID LEVEL
2. CHANGE HYDRAULIC OIL, FILTER AND INSPECT STRAINER ANNUALLY
3. REPLACE OIL WITH MV 32 HYDRAULIC OIL OR EQUIVALENT
4. CAPACITY: SEE OWNER'S MANAUL FOR TANK SIZE
MAXIMUM RPM IS SET AT THE FACTORY
TO APPROXIMATELY 22222 00 RPM
DO NOT ALTER THIS RPM (REFER TO MANUAL
ON HEATED HOSE MODELS)
ENGINE RPM
* Use dipstick to verify
level when filling
Capacity: 150 - 21 Gal.
230 - 26 Gal.
410 - 36 Gal.
Replace with an ISO 68 heat transfer oil or equivalent
OIL MAY BE VERY
HOT! ALLOW TO COOL
BEFORE REPLACING OR
CHECKING LEVEL.
WARNING!
!
Vent
Plug
3
0
0
°C
°F
1
5
0
100
2
0
0
65
4
0
0
150
200
350
7
5
0
400
7
0
0
300
5
0
0
250
Vent plug must be
removed when filling
tank with heat
transfer oil.
Oil
Thermometer
6
0
0
WARNING:
TO PREVENT
BODILY INJURY
AGITATOR
PRESSURE
GUAGE
MATERIAL
PRESSURE
GUAGE
TO PREVENT
BODILY INJURY
WARNING:
!
!
22222
