CIMLINE C1 - Rock Burner Internal Wiring Diagram

36
Rock Burner Internal Wiring Diagram
87
87a
30
86
85
A B
(16)
(19)
(22)
(21)
(20)
(23)
(18)
(17) (14)
(15)
(13)
(12) (11)
(10)
(9)
(7)
A B C D
1 BLACK GROUND FROM RELAY 2 WHITE POWER FROM RELAY 3 WHITE OR RED MAIN POWER TO BURNER 4 WHITE BURNER INPUT 5-8 YELLOW CAD CELL 9-17 GROUND 18 ORG MOTOR AND VALVE POWER 19 RED MOTOR AND VALVE POWER 20 BLUE IGNITER POWER 21 RED IGNITER POWER 22-23 VALVE POWER
ENABLE
GND MTR
CAD CELL
MOTOR
GND IGN
IGNITER
GND VLV
ALARM VALVE
30
10
Black
Brown
White
(8)
(6)
(5)
(4) WHITE
Red
RELAY
