CIMLINE C1 - Hydraulic Reservoir and Diesel Tank Components

48
Hydraulic Reservoir and Diesel Tank Components
# PART # DESCRIPTION
1 172618 HYDRAULIC TANK
2 172619 DIESEL TANK
3 172127 RETURN FILTER ASSY (NON-COMPRESSOR)
4 170407 ELEMENT - RETURN FILTER (NON-COMPRESSOR)
5 152044 FILLER CAP ASSY
6 171631 SIGHT GAUGE
7 172186 SUCTION STRAINER
8 155396 FUEL GAUGE/CAP
9 120743 FUEL SHUT-OFF VALVE
10 170169 FUEL FILTER
10
7
1 1
2
6
3
4 5
8
9
9
