49
Combustion Chamber Parts List
404518 - COMPLETE ASSEMBLY (ITEMS 1-11)
# PART # DESCRIPTION QTY.
1 403400 CHAMBER LINING KIT 1
2 402898 BURNER MOUNT 1
3 402893 HEAT CHAMBER SKIN 1
4 417041 INSPECTION COVER 1
5 152487 INSULATION HEAT CHAMBER 1
6 100125 WASHER-FLAT .31 16
7 100093 WASHER-SPLIT LOCK .38 2
8 100092 WASHER-SPLITLOCK .31 8
9 100068 NUT-HEX .31 8
10 100015 BOLT, HEX 3/8-16 X 3/4 2
11 100006 HHCS .31 X 1.0 8
