Mastic Control Panel
# PART # DESCRIPTION QTY.
1 430376 PLATE - CONTROL PANEL 1
2 DIN TERMINAL 1
3 130834 CONTROLLER MATERIAL 1
4 130883 SELECTOR SWITCH 1
5 130122 SWITCH 1
6 130921 CONTROL PANEL 1
7 152119 FUSE HOLDER 1
8 430386 PLATE - CONTROL 1
SEE MASTIC INTERNAL WIRING DIAGRAM ON PAGE 33
FOR WIRING CONNECTIONS TO THE PLUGS ABOVE.
