52
Mixing Chamber
# PART # DESCRIPTION QTY.
1 430333 PLATE - CHAIN TIGHTENER 1
2 425696 ROD ADAPTER 1
3 409689 EAR WELDMENT 1
4 409545 VALVE SUB-ASSY 1
5 409543 VALVE PLATE SUB-WELD 1
6 409542 MIXING CHAMBER SUB-WELD 1
7 172395 CYLINDER 1.125 BORE 3IN STROKE 1
8 170602 MOTOR-45 CU IN 1
9 170449 LOAD ADAPTER- M 1
10 156158 STUB SHAFT 1
11 156136 MIXING FLIGHTING 1
12 130581 3/8-24 CLEVIS 1
13 111885 SPROCKET 50B16 1
14 111884 SPROCKET 50B16 1
15 110988 ROLLER CHAIN NO 50 1
16 110683 BEARING-FLANGE .62 1
17 110294 KEY .38 X 2.00 LG 1
18 100486 HHCS .50 X 4.5 FULL THD GR5 ZP 1
# PART # DESCRIPTION QTY.
19 100463 WASHER-FLAT-SAE .31 5
20 100242 NUT-HEX .38-24 UNF 1
21 100221 SPRING PIN 3/16" X 1.50 1
22 100211 WASHER-FLAT-SAE .38 4
23 100163 HHCS-.38 X 3.50 4
24 100126 WASHER-FLAT .38 8
25 100125 WASHER-FLAT .31 8
26 100093 WASHER-SPLIT LOCK .38 16
27 100092 WASHER-SPLITLOCK .31 6
28 100071 1/2-13 HEX NUT 1
29 100069 NUT-HEX .38 4
30 100068 NUT-HEX .31 2
31 100017 HHCS .38 X 1.25 4
32 100016 HHCS .38 X 1.00 2
33 100015 BOLT, HEX 3/8-16 X 3/4 6
34 100009 HHCS .31 X 1.75 1
35 100007 HHCS .31 X 1.25 GR5 ZP 2
36 100006 HHCS .31 X 1.0 4
