SAFETY - PRECAUTIONS AND FEATURES
6
Figure 1-1: Communication Plates
Note: CSZ is continuously upgrading the components used in its
equipment. Consequently, the physical appearance of certain
components may vary from that shown.
Connection for event relay(s). Do not connect 115-volt
power to these connections. Customer events should only
be connected to a 24VDC/AC source. See EZT-570S User
Manual for exact specifications.
COMMUNICATION
CONNECTIONS
CONNECTION
FOR EVENT RELAY
