GENERAL DESCRIPTION
20
SHELF DESCRIPTION
Figure 2-8: Shelf and Bracket
Figure 2-9: Shelf in Pulled Out Position
“C” channel shelf rail is not
a mechanical stop to
prevent the shelf from
being pulled all the way
out.
WARNING
Shelves pulled more than
halfway out can become
unstable.
WARNING
Test samples should be
placed in the chamber in a
manner that allows proper
ventilation.
WARNING
Shelf
Rail
“C” Channel
Shelf Rail
Plenum Wall
with Holes
for Shelf Rail
