Cincinnati Sub-Zero ZP Series - Figure 2-7: Chamber Interior

GENERAL DESCRIPTION
16
PLENUM COVER REMOVED
PLENUM COVER ON
Figure 2-7: Chamber Interior
Product
Sensor
Solid State
Humidity Sensor
(behind cover)
Air Temperature Sensor
(behind cover)
Plenum
Cover
Wet Coil
Pan
Note: CSZ is continuously upgrading the components used in its equipment. Consequently, the physical
appearance of certain components may vary from that shown.
Fans
Chamber Light
Heaters
Evaporator
Coil
Dehumidification
Coil
Plenum
Area
