Cincinnati Sub-Zero ZP Series - Figure 2-2: ZPRC Chamber - Side View; Figure 2-3: ZPRC Chamber - Top View

GENERAL DESCRIPTION
10
Figure 2-2: ZPRC Chamber – Side View
Figure 2-3: ZPRC Chamber – Top View
Note: CSZ is continuously upgrading the
components used in its equipment.
Consequently, the physical appearance of certain
components may vary from that shown.
Blower Motor
Adjustable
Supply Air
Damper
Supply Air
Return Air
