Cincinnati Sub-Zero ZP Series - Figure 2-1: Chamber Components Location

GENERAL DESCRIPTION
9
Figure 2-1: Chamber Components Location
Note: CSZ is continuously upgrading the components used
in its equipment. Consequently, the physical appearance
of certain components may vary from that shown.
Lower Refrigeration Components
Upper
Refrigeration
Components
Water Inlet
Location
Steam
Generator
System
Water Cooled
Condenser Connection
location (Knockouts) (If
Applicable)
Chamber Vent
Dry Air Purge
(Optional)
Electrical Connection
(1 ¼” EMT Conduit – 35mm
Metric Conduit Trade Size)
LN2 Boost
Valves
(Optional)
