GENERAL DESCRIPTION
21
Table 2-1: ZP(H) Specifications
* -Tolerances are based upon the full temperature range of the chamber. Better control will be achieved across
a limited range.
Single Stage -34° C to 190° C
Live Load Capacity
Electrical Power Requirements
Watts
Full Load Amps
Model
-18° C
-34° C
208-230V, 1Phase
208-230V, 3Phase
ZP-8-2-H/AC
1200
250
34
30
ZP-16-2-H/AC
1200
250
34
30
ZP-32-2-H/AC
1200
250
34
30
ZP-44-2-H/AC
2000
300
43
38
ZP-64-2-H/AC
2000
300
43
38
Table 2-2: ZP Load Capacity and Electrical Requirements
Table 2-3: ZP Single Stage Specifications
ZP(H) - 8
ZP(H) - 16
ZP(H) – 32
ZP(H) - 44
ZP(H) - 64
ZP(H) - 80
ZP(H) - 96
Workspace
Volume
8 Cubic Ft
(230 L)
16 Cubic FT
(450L)
32 Cubic Ft
(900 L)
44 Cubic Ft
(1,250)
64 Cubic Ft
(1,801L)
80 Cubic Ft
(2,265L)
96 Cubic Ft
(2,718 L)
Exterior
Dimensions (cm)
W x D x H
36” x 57” x 76”
(91 x 145 x 193)
42” x 63” x 82”
(107 x 160 x 208)
50” x 71” x 91.5”
(127 x 180 x 232)
56.5” x 71” x 99.5”
(143.5 x 180 x 253)
60.5” x 81” x
101.5”
(154 x 205 x 258)
67” x 94” x 101.5”
(170 x 238 x 258)
60” x 105” x 101.5”
(154 x 266 x 258)
Workspace
Dimensions (cm)
W x D x H
24” x 24” x 24”
(61 x 61 x 61)
30” x 30” x 30”
(76 x 76 x 76)
38” x 38” x 38”
(97 x 97 x 97)
44” x 38” x 46”
(112 x 97 x 117)
48” x 48” x 48”
(122 x 122 x 122)
48” x 60” x 48”
(122 x 152 x 122)
48” x 72” x 48”
(122 x 183 x 122)
Temperature
Ranges
Single Stage: -34° C to +190° C (-30°F to 375°F)
Tundra®: -45° C to +190° C (-49°F to 375°F)
Cascade: -70° C to +190° C (-94°F to 375°F)
Temperature
Control
Tolerance*
+/- 0.5° C at steady state condition after stabilization
Humidity Range
Optional Range
10% TO 98% RH
5% TO 98% RH
*Humidity
Control Tolerance
+/- 3% RH at steady state conditions after stabilization
Distributed Shelf
Load Capacity
110 lbs. 110 lbs. 100 lbs. 100 lbs. 100 lbs. 100 lbs. 100 lbs
Single Stage -34° C to 190°
Cooling Performance
with Empty Chamber in Minutes
from:
Heating Performance
with Empty Chamber in Minutes from:
24° C
24° C
-34° C
Model
-18° C
-34° C
93° C
190° C
24° C
ZP-8-2-H/AC
6
18
10
30
10
ZP-16-2-H/AC
8
22
15
50
12
ZP-32-2-H/AC
10
28
20
72
15
ZP-44-2-H/AC
15
401
20
60
15
ZP-64-2-H/AC
20
50
25
75
20
