INSTALLATION
62
Figure 4-2: Installation Locations
Demineralizer Filter
(Optional with Humidity)
Water Inlet
Location
Drain Valve
Recirculating Water
(Optional with Humidity)
Dry Air Purge
(Optional)
Electrical
Connection
Upper Refrigeration
LN2 Vent
(Must be vented outdoors)
R-508B
Compressor
System #2
R-404A
Compressor
System #1
Pressure
Gauges
Float Switch
Enclosure
Steam Generator
Assembly
Pump
Water Cooled Condenser
Connections (If Applicable)
Float
Switch
Note: CSZ is continuously upgrading
the components used in its
equipment. Consequently, the
physical appearance of certain
components may vary from that
shown.
