CipherLab 1105 User Manual

1
Update
CipherLab Barcode Scanners provide convenient and versatile solutions to meet your
business needs. The tethered handheld scanners are designed to help accelerate
productivity while lowering the total cost of ownership. Intensive data collection jobs are
made easier with fast, accurate barcode scanning in retail, industrial, manufacturing, and
enterprise environments.
Owing to the compact design, extremely low power consumption, and powerful decoding
capability, CipherLab Barcode Scanners are the best choice for the following
applications –
 Receiving in Retail
 Product labeling & Tracking
 Shelf Product Replenishment
 Mobile Point of Sale (POS)
 Mobile Inventory Management
 Order Picking & Staging
 Work-In-Process Tracking
 Material Flow Control
 Transportation & Distribution
 Warehousing
 Asset Management
This manual contains information on operating the scanner and using its features. We
recommend you to keep one copy of the manual at hand for quick reference or
maintenance purposes. To avoid any improper disposal or operation, please read the
manual thoroughly before use.
Thank you for choosing CipherLab products!
INTRODUCTION

CipherLab 1105 Specifications

General

Type	Handheld bar code reader
Wavelength	630 nm
Sensor type	Laser
Read rate (max)	100 reads/s
Pitch reading angle	-70 - 70 °
Optical sensor resolution	3648 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	-
Connectivity technology	Wired
Product color	Gray
Housing material	Polyurethane
Power consumption (standby)	0.06 W
Power consumption (typical)	0.190 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	145 mm
Width	93 mm
Height	64 mm
Weight	165 g
