Chapter 1 Understanding the Barcode Scanner
1.4.1 CONTINUOUS MODE
The scanner is always scanning.
 After a successful decoding, the removal of barcode is required. It is not allowed to
proceed to decode until the preset decoding delay time has passed.
 To decode the same barcode repeatedly, move away the barcode and put it back
again and again for scanning.
Note: Refer to “Delay between Re-read”.
Continuous Mode
1.4.2 TEST MODE
The scanner is always scanning.
 Capable of decoding the same barcode repeatedly without removing it, for testing
purpose.
Test Mode
1.4.3 LASER MODE
The scanner will start scanning once the trigger is held down.
 The scanning won't stop until (1) a barcode is decoded, (2) the pre-set timeout
expires, or (3) you release the trigger.
Note: Refer to “Scanning Timeout”.
*Laser Mode
Note: By default, the scan mode of 1100/1105 is set to Laser mode.

CipherLab 1105 Specifications

General

Type	Handheld bar code reader
Wavelength	630 nm
Sensor type	Laser
Read rate (max)	100 reads/s
Pitch reading angle	-70 - 70 °
Optical sensor resolution	3648 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	-
Connectivity technology	Wired
Product color	Gray
Housing material	Polyurethane
Power consumption (standby)	0.06 W
Power consumption (typical)	0.190 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	145 mm
Width	93 mm
Height	64 mm
Weight	165 g
