CipherLab 1105 User Manual

117
Update
1000, 1090+
Optical Characteristics
1000 1090+
Scan Engine Contact type Contact type
(Barcode width up to 90 mm)
Optical Sensor CCD, 2048 pixels CCD, 2048 pixels
Light Source Red LED Red LED
Wavelength 625 nm 625 nm
Physical Characteristics
Switch Rubber switch
Indication Dual-color LED (Red/Green) and beeper
Interface Options Keyboard, RS-232
USB HID, USB Virtual COM
IBM 4683/4694
See accessories below.
Weight Approx. 265 g
(including cable)
Approx. 148 g
SPECIFICATIONS

CipherLab 1105 Specifications

General

Type	Handheld bar code reader
Wavelength	630 nm
Sensor type	Laser
Read rate (max)	100 reads/s
Pitch reading angle	-70 - 70 °
Optical sensor resolution	3648 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	-
Connectivity technology	Wired
Product color	Gray
Housing material	Polyurethane
Power consumption (standby)	0.06 W
Power consumption (typical)	0.190 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	145 mm
Width	93 mm
Height	64 mm
Weight	165 g
