26
Enter Setup
1500 Barcode Scanner
User Guide
1.8 DELAY BETWEEN RE-READ
This is also referred to as t
he “Blocking Time”, which
is used to prevent the scanner from
accidentally reading the same barcode tw
ice
w
h
e
n
t
h
e
s
c
a
n
m
o
d
e
i
s
s
e
t
t
o
a
n
y
o
f
t
h
e
following –
Continuous mode
Auto Power Off mode
Alternate mode
100 ms
200 ms
*400 ms
800 ms
1 sec
2 sec
3 sec
5 sec
37
39
