74
Enter Setup
1500 Barcode Scanner
User Guide
3.9.4 SECURITY LEVEL
Security Level renders more decoding accuracy
giving consideration to barcodes’ printed
quality. Decide th
e security level for reading EAN-
13 barcodes.
Normal
*High
85
87
