52
Enter Setup
1500 Barcode Scanner
User Guide
2.3.5 MARGIN TIME
By default, it is set 20 milliseconds as the time span for
the change in state for bar and
space modules. Select other valu
e for the margin time.
5 ms
10 ms
*20 ms
30 ms
40 ms
60 ms
80 ms
100 ms
Note:
Margin Time is applied only
when the signal level for No
rmal State and Bar State is
the same.
63
65
