Enter Setup
1500 Barcode Scanner
User Guide
Digits Transmission
By default, the alphanumeric keypad is used for tr
ansmitting d
igits. Select
“Numeric Ke
ypad” if you
wish to use the keys on the numeric keypad.
Numeric Key
*Alphanumeric Key
Note: If you select “Numeric Keypad”, the Num Lock status of the physi
cal keyboard
should be “ON”.
53
55
