CipherLab 8200 User Manual

213
Appendix II Symbology Parameters
CODE 11
The support of Code 11 on Long Range scan engine is currently implemented for 8300
only.
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
96 1: Enable Code 11
0: Disable Code 11
1 2D,
8300 –
LR
only
Note: By default, Code 11 is disabled on 8200/8400/8700.
116 1: Code 11 Length Limitation in Max/Min Length Format
0: Code 11 Length Limitation in Fixed Length Format
0 2D,
8300 –
LR
only
117 Code 11 Max Code Length / Fixed Length1 0 2D,
8300 –
LR
only
118 Code 11 Min Code Length / Fixed Length2
Note
Length1 must be greater than Length2.
0 2D,
8300 –
LR
only
170 Code 11 Check Digit Verification
2: Two check digits
1: One check digit
0: Disable
0 2D,
8300 –
LR
only
Length Qualification
The barcode can be qualified by “Fixed Length” or “Max/Min Length”. The length of a barcode
refers to the number of characters (= human readable chara
cters), including check digit(s) it
contains.
 If “Fixed Length” is selected, up to 2 fixed lengths can be specified.
 If “Max/Min Length” is selected, the maximum length and the minimum length must be
specified. It only accepts those barcodes with lengths
that fall between max/min lengths
specified.
Note: When it is configured to use Fixed Length format, Length1 must be greater than
Length2. Otherwise, the format will be converted to Max/Min Length Format, and
Length1 becomes Min. Length while Length2 becomes Max. Length. In either
length format, when both of the values are configured to 0, it means no limit in
length.

CipherLab 8200 Specifications

General

IP Rating	IP54
Display Type	LCD
Barcode Scanner	Laser
Connectivity	RS-232
I/O Ports	RS-232
