203
Appendix II Symbology Parameters
124 Codabar Min Code Length / Fixed Length2
Note
Length1 must be greater than Length2.
0
Long Range
Transmit Start/Stop Character
Decide whether or not to include the start/stop characters in the data being transmitted.
The barcode can be qualified by “Fixed Length” or “Max/Min Length”
. The length of a barcode
refers to the number of characters (= human
readable characters), including check digit(s) it
contains.
If “Fixed Length” is selected, up to 2 fixed lengths can be specified.
If “Max/Min Length”
is selected, the maximum length and the minimum length must be
specified. It only accepts those barcodes
with lengths that fall between max/min lengths
specified.
Note: When it is configured to use Fixed Length format, Length1 must be greater than
Length2. Otherwise, the format will be converted to Max/Min Length Format, and
Length1 becomes Min. Length while Length2 becomes Max. Length. In either
length format, when both of the values are configured to 0, it means no limit in
length.
CODE 2 OF 5
INDUSTRIAL 25 (DISCRETE 25)
Values (N2%) & Description
98 1: Enable Industrial 25 (Discrete 25)
0: Disable Industrial 25 (Discrete 25)
1
Long Range
119
1: Industrial 25 (Discrete 25) Length Limitation in Max/Min
Length Format
0: Industrial 25 (Discrete 25) Length Limitation in Fixed
Length Format
0
Long Range
120 Industrial 25 (Discrete 25) Max Code Length / Fixed Length1 0
Long Range
121 Industrial 25 (Discrete 25) Min Code Length / Fixed Length2
Note
Length1 must be greater than Length2.
0
Long Range
Because of th
e weak structure of the 2 of 5 symbologies, it is possible to make a “short scan”
error. To prevent the “short scan” error, define the “Length Qualification” settings to ensure that
the correct barcode is read by qualifying the allowable code length. Refer to Codabar.
To Next Page
