CipherLab 8200 User Manual

214
CipherLab BASIC Programming Part I
2D SCAN ENGINE ONLY
In addition to those symbologies described previously, the 2D scan engine supports the
following symbologies:
1D SYMBOLOGIES
CHINESE 25
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
169 1: Enable Chinese 25
0: Disable Chinese 25
0
8200, 8400,
8700 -2D
MATRIX 25
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
6 1: Enable Matrix 25
0: Disable Matrix 25
0
8200, 8400,
8700 -2D
32 1: Verify Matrix 25 Check Digit
0: DO NOT verify Matrix 25 Check Digit
0
8200, 8400,
8700 -2D
33 1: Transmit Matrix 25 Check Digit
0: DO NOT transmit Matrix 25 Check Digit
0
8200, 8400,
8700 -2D
64 1: Matrix 25 Code Length L
imitation in Max/Min Length
Format
0: Matrix 25 Code Length Limitation in Fixed Length Format
1
8200, 8400,
8700 -2D
65 Matrix 25 Max Code Length / Fixed Length 1 0
8200, 8400,
8700 -2D
66 Matrix 25 Min Code Length / Fixed Length 2
Note
Length1 must be greater than Length2.
0
8200, 8400,
8700 -2D
UPC/EAN — BOOKLAND ISBN FORMAT
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
161 UPC/EAN – Bookland ISBN Format
1: UPC/EAN – Bookland ISBN 13
0: UPC/EAN – Bookland ISBN 10
0
8200, 8400,
8700 -2D
