21
Chapter 1
Using 8300 Mobile Computer
1.7 COMMUNICATIONS VIA THE CRADLE
1.7.1 SETTING UP THE CRADLE
The cradle is designed for charging and communications at the same time. You may
choose a cradle type that best suits your needs.
1) Place the cradle on a flat and clean surface.
2) Connect the power supply cord to the power jack on the back of the cradle, and then
connect the other end of the power supply cord to a suitable power outlet. The cradle
is ready for charging the mobile computer.
3) Seat the mobile computer in the cradle.
If data communications are desired at the same time, you can establish a proper
connection with a computer or remote host. Refer to the Installation Guide of your
cradle.
1.7.2 CRADLE OPTIONS
The following cradle types are available on order —
Cradle Type
Charging & Comm. Cradle
Modem Cradle Ethernet Cradle
POWER Jack
√ √ √
RS-232 Port
√ √ √
Figure 6: Setting up cradle
