CipherLab 8300 Reference Manual

37
Chapter 3 System Menu
3.3 TESTS
Here provides functional tests for key parts.
3.3.1 READER
The supported symbologies depend on the scan engine you use. Refer to section 1.6
Data Capture for symbologies that are enabled by default. For symbologies that are
disabled by default, they must be enabled through programming.
 Test the reading performance of the scanner. Press [SCAN] to start.
 To stop and exit the test, press any key.
3.3.2 BUZZER
Test the buzzer with different frequency/duration combinations. Press [Enter] to start. To
stop and exit the test, press any key.
3.3.3 LCD & LED
Test the LCD display and LED indicator. Press [Enter] to start. To stop and exit the test,
press any key.
3.3.4 KEYBOARD
Test the rubber keys. Press any key and its corresponding character will be shown on the
screen. To stop and exit the test, press [ESC].
3.3.5 MEMORY
Test the data memory (SRAM), and the results will be shown on the screen. To stop and
exit the test, press [ESC].
Warning! The contents of the data memory (SRAM) will be wiped out after test.
3.3.6 ECHO TEST
After a physical connection is established properly, run the utility “Echo Test” on your
computer and start this test on your mobile computer. Select a desired baud rate. To
stop and exit the test, press [ESC].
