CipherLab 9700 User Manual

131
Chapte
r
4 Manage Mobile Computer
POWER
Displays battery level and sets up power plans. Two tabs are featured – Battery and
Power Off.
Tabbed Page
Description
Battery Delivers a summary of battery level for main & backup batteries,
and also denotes the main battery level percentage.
Schemes Sets a power scheme to switch the mobile computer to suspend
after a specified amount of time.
READER CONFIG
Allows users to set scanner preferences, data output format and destination,
symbology settings, and perform test scanning of barcodes. See Use Reader Config.
REGIONAL SETTINGS
Controls how to display date, time and numbers, currency as well as interface and input
language on the mobile computer. Featured tabs are – Region, Language and Input.
Note: Default interface language and input language are bound to the OS and cannot
be changed.
REMOVE PROGRAMS
Views and removes non-inherent applications installed on the mobile computer. See
also Uninstall Applications
.
SCREEN ROTATION
Selects the modes to enable for screen orientation, and whether to suspend the mobile
computer when it is facing down.
Tap each of the following labels to enable/disable the given screen rotation mode.
 Portrait mode
 Landscape mode
 Signature mode
Tap the following label to enable/disable suspension of the mobile computer when it is
turned over and the screen is facing downwards.
 Suspend when face down
SCU
Summit Client Utility (SCU) allows changing Wi-Fi settings on the mobile computer,
including radio type, access point, Wi-Fi security and more. Settings are displayed
among three tabs:
Tabbed Page
Description
Status Displays AP information, device IP, connection status and signal strength.
Configuration Disables/Enables radio and switches the active profile. Also opens profile
settings and global settings.
Diagnostics Performs diagnostic tests to check connection, and shows information
about SCU version.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
