CipherLab RK25 Reference Manual

60
RK25 Mobile Computer
2) Observe the red light on the front panel; as it goes off, the device is in complete suspend
mode and Main battery is ready to be replaced. Fellow the steps described in Install/
Remove Battery to remove the battery and replace it with the new one.
3) When the main battery is removed, system can stay in suspend mode at least 5 minutes.
Please replace with a fully-charged main battery as soon as possible.
4) Make sure the battery latch is properly locked before pressing the power button to wake
up the mobile computer from suspend mode.
Warning:
Please do not perform a battery swapping before the mobile computer’s OS is ready. Removing the
battery cover during powering up your mobile computer may cause system failure.
Note:
(1) When main battery is removed, the system will stay in suspend mode for at least 5 minutes. To
prevent the system from being shut down without advance warning, please DO replace the
main battery within the 5 minutes.
(2) Backup battery keeps the mobile computer in suspension when the main battery is depleted.
Thus, to prevent data loss, DO NOT replace the main battery when backup battery’s power is
low. Please connect RK25 mobile computer with the external power source to charge it till the
“Low Sub Battery” notification icon disappears from the status bar. Once the “Low Sub Battery”
notification disappears, the main battery replacement could be proceeded.
