3) After the chamber is revealed, insert SIM cards, the SAM card and the microSD card
into their respective sockets. Close and push back the hinged cover till a click sounds.
To Install the Cards:
1) Slide the hinged cover back.
2) Swing the top to open.
3) Insert the cards, close the hinged cover, and then push it back.
4) Place the inner lid back, install the battery cover, and push the battery latch back to
the “Lock” position.
1. Slide the hinged cover.
4. Slide the hinged cover to lock.
3. Close the hinged cover.
