----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 15
5.- SETUP PROCEDURE
The SETUP procedure of the CVM 96 is performed by means of several
SETUP options.
) For accessing the SETUP menu the keys max & min must be
simultaneously pressed once the instrument is at the main screen.
When accessing the SETUP, the message "SETUP unloc " (1) is shown for
some seconds on screen, or, otherwise, the message "SETUP loc" (2).
(1) SETUP UNLOC (SETUP unlocked ) : when the SETUP is accessed,
configuration parameters can be either visualized and modified.
(2) SETUP LOC (SETUP locked ) : when the SETUP is accessed,
configuration parameters can be visualized but cannot be modified .
Once into the SETUP, use the keyboard to select different options and enter
required variables:
- The key
validates de value and pass to the next menu.
- The key MAX permits to select among different options in a menu, or to
increase a digit when a variable is being entered.
- The key MIN permits to move the cursor along the digits.
Different options are following shown in a sequential mode:
1. Choice of visualization of phase-to-neutral or phase-to-phase voltages
2. Voltage display mode
3. Voltage transformation ratio.
4. Value of the current transformer primary : 1 a 10000 A
5. Power demand meter setting
6. Choice of default initial screen
7. Time for display shutdown
8. Deleting energy counters
9. Choice of harmonic distortion determination mode: d% or THD%
10. Setting alarms : RELAY 1 (OUT 1) & RELAY 2 (OUT 2)
