----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 35
10.3.- RS-232 TYPE CONNECTION TO A RS-232 TYPE INPUT OF A PC
4 Rx
3 Tx
5 GND
7
5
2
3
RS-232
DB-9
PC
CVM-96
CVM-96
8
CVM 96
CVM 96
