----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 42
11.- APPENDIX A: Second SETUP of the CVM 96
A second SETUP menu is accessible in order to perform the configuration of
the CVM 96 with other features different from factory-supplied ones.
To access this menu proceed as follows:
- Being the CVM 96 powered off, simultaneously press " ", "max" and
"min" keys.
- Holding these keys pressed, powered the CVM 96 on.
Following messages will be then shown on display:
a.- COMMUNICATION PROTOCOL: MODBUS
SET
PROT Protocol:
BUS
( MODBUS (c) (BUS) protocol
(*) See related section in this manual
- " " key: to validate the choice and pass to the next SETUP screen:
b.- SETTING COMMUNICATION PARAMETERS
SET
Cdef Default configuration
NO
( "max" key to switch from NO / YES
- If YES is chosen: the configuration is 001 / 9600 / 8 bits / N / 1 bit
