----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 20
5.6.- Initial screen setting
This option allows choice among fixed or rotary screen:
a.- Fixed screen (choice is switch just pressing ): choice among 10 available
screen of the initial screen to be shown when the CVM 96 is powered (or when the
CVM 96 is reset).
b.- Rotary screens: all 10 screens are successively shown at intervals of 5 s.
This option is noticed by means of some leds:
SET
dEF
PAGE
- The key "max": permits to modify the selected page. The led of the selected option
will be on. Whether rotary screens option is selected, then all leds will be on.
- Press " " to validate the choice.
5.7.- Setting of the display shutdown time
Setting of the period of time to go by, from the moment that the CVM 96
keyboard is not touched anymore, before the CVM display is automatically shut down
(low consumption mode):
dISP
OFF
05
→ Time to shutdown (Minutes)
When the display is shut down, a Led at the bottom left corner of the CVM will
keep blinking. The display will be automatically turned on when any CVM key is
pressed.
- "max" key: to modify the value of the blinking value.
- "min" key: to validate the blinking value and go to the next digit.
