----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 19
NOTES:
- The secondary of the current transformers is not programmable. It is
automatically set at 5 A (... / 5 A ac)
- The primary current value to be set is also limited by the following condition:
The maximum allowable primary current value which can be set is defined by
the fact that the multiplication of the primary voltage value by this primary
current value cannot exceed 20,000,000.
5.5.- Setting power demand utility screens.
Push the key " " and the following screens will appear by display:
1.- PARAMETER TO CONTROL ("Pd Code xx")
None
00
Three phase active power kW III
16
Three phase apparent power kVA III
34
Average three-phase current AIII
36
Current per phase A1 – A2 – A3
A-PH
Value of power integrated during the programmed demand period.
2.- DEMAND PERIOD ( 1 to 60 min.) ("Pd Per xx")
3.- CLEAR MAXIMUM VALUE IN MEMORY
("CLr Pd xx") no or YES
Programming mode:
- "max" key: allows choosing the different available options.
- "min" key: allows the validation of the blinking digit and go forward to the next
digit (only for the "Pd Per xx" option).
- To pass to the next option press "
".
If you don't want to modify anything, just press the "
" key three times without
modifying any value.
