----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 16
5.1.- Phase-to-Phase or Phase-to-Neutral voltages
After the word "set" you will see on the three displays the voltages of the
phases L1, L2, L3.
U1 U12
U2 or U23
U3 U31
Phase to Neutral Voltages: U1, U2, U3
Phase to Phase Voltages : U12, U23, U31
a.- To select one of the voltage options just press the green key "max" and both
options will appear alternately.
b.- When you get in the display the desired option just press the " " key to
validate it and access to the next SETUP option.
5.2.- Voltage display mode
This option permits the user to select the voltage display mode. That way, the choice
between viewing the voltage with one decimal digit or without decimals is user-
programmable.
SEt SEt
Udec ó Udec
no YES
No decimals 1 decimal digit
a) To select one of the voltage options just press the green key "max" and both
options will appear alternately.
When you get in the display the desired option just press the "
" key to validate it
and access to the next SETUP option.
