----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 41
b.- Reading digital outputs (relays) - Function 01 :
Inquiry : PP0100000008CRC (PP = peripheral No.)
Answer : PP0101XXCRC
Where XX (hexadecimal byte) Æ translated to binary
b7 b6 b5 b4 b3 b2
b1 b0
bit b0 = relay 1 ( 1 = ON ; 0 = OFF)
bit b1 = relay 2 ( 1 = ON ; 0 = OFF)
c.- Write of digital outputs
This function is used to force the status of the CVM 96 digital outputs.
Output No. Message Answer
Relay 1
Relay 2
PP050000xx00 CRC
PP050001xx00 CRC
PP050000xx00 CRC
PP050001xx00 CRC
Where: PP Æ peripheral No.
xx Æ 00 Deactivate
Æ FF Activate
