----- Supply network analyzer CVM 96 Ethernet -------- ----- Page No. 29
; The DELAY set value is applied either to the connection or the
disconnection when the alarm conditions occur.
; User-definable units for the different parameters are:
Parameter Format Example
Voltage With decimals = V (xxxx)
Without decimals = kV (xxx.x)
125.0 = 125 kV
0220 = 220 V
25.30 = 25.30 kV
Current A 0150 = 150 A
Powers kW, kvarL, kvarC 0.540 = 540 W
250.5 = 250.5 kW
Energies kWh, kvarLh, kvarCh
Power factor +/- x.xx - 0.70
Frequency xx.x 50.0 = 50 Hz
2 Output relay connection lay-out CVM 96...-C2 (2 relays ) :
Out1 Terminals Signal Out2 Terminals Signal
RELAY
1
10 - 12 N.O.
RELAY
2
11- 12 N.O.
