Circutor Raption Series Service Manual

Service Manual 17
Raption
1- Filters kit
2- Upper power modules (A5.1/
A5.2) for Raption 50
2- Upper power modules (U6.1/
U6.2) for Raption 50 HV, Raption
50 EVO and Raption 100
3- Lower power modules (A5.3/
A5.4) for Raption 50
3- Lower power modules (U7.1/
U7.2) for Raption 50 HV, Raption
50 EVO and Raption 100
4- Ventilation chamber access 5- Filters kit
6- Centrifugal fan for power
stage (M13.1) for Raption 50
6- Centrifugal fans for power
stage (M16.1/M16.2/M16.3) for
Raption 50 HV, Raption 50 EVO
and Raption 100
7- Filters kit
8- Power module 12.5kW 1 (A5.1)
for Raption 50
8- Power module 25kW 1 (U6.1)
for Raption 50 HV, Raption 50
EVO and Raption 100
(3)
9- Power module 12.5kW 2
(A5.2) for Raption 50
9- Power module 25kW 2 (U6.2)
for Raption 100
10- Centrifugal fan for power
stage (M13.1) for Raption 50
10- Centrifugal fans for power
stage (M16.1/M16.2/M16.3)
for Raption 50 HV, Raption 50
EVO and Raption 100
11- Air outlet filters
12- Power module 12.5kW 3
(A5.3) for Raption 50
12- Power module 25kW 3 (U7.1)
for Raption 50 HV, Raption 50
EVO and Raption 100
(3)
13- Power module 12.5kW 4
(A5.4) for Raption 50
13- Power module 25kW 4
(U7.2) for Raption 100
(3)
Depending on the model, the location of Raption 50 HV and Raption 50 EVO
power modules may vary. In case of doubt, contact our Post-Sales Department.
