Raption
66 Service Manual
LOCATING THE ERROR:
1.- Which connectors are in error?
Identifying the connector(s) in fault, will indicate us which
components have to be checked. Basically the ones related
with the faulty connector(s).
For example, Mode 3 is related only with AC charging ses-
sions and CCS board is related only with CCS ones.
2.-In which step of the charging session the error shows
up?
• Charging session does not even start
• During initial checks.
• Starting process.
• Randomly during charging session.
• Stopping process.
• Permanent error.
• 3.- Does the error appear with a specific car model?
CIRCUTOR performs interoperability tests periodically with
the new brand cars of the market in order to ensure a cor-
rect compatibility between charging stations and EVs.
Another important point is to locate the error. It is basic to identify which connector is
affected and find in which moment EVSE is going into the error state.
By doing this, components that could cause the error will be located.
