Raption
119Instruction Manual
Technical Data
STANDARDS
IEC 61851-1; IEC 61851-23; IEC 61851-21-2; CE / Combo-2; CHAdeMO compatible; CCS (DIN 70121;
ISO 15118)
(7)
520 mm with the cables hanged.
(8)
Depending on the model, these components are optionals.
ELECTRICAL DATA
Power supply 3P+N+PE
Model for 480 V mains:
Power supply III
3P+N+PE
Voltage range 400 V~ ± 10%
Model for 480 V mains:
Voltage range III
480/277 V~ ± 10%
Model for 480 V mains:
Power supply II
P + N
Model for 480 V mains:
Voltage range II
208-240 V~ ± 10%
Power factor > 0.98
Efficiency 95 % at nominal output power
Standby consumption 38 W
THDi < 5%
Frecuency 50/60 Hz
Model for 480 V mains: Frecuency 60 Hz
Electrical protections
(8)
Overcurrent protection, RCD and Overvoltage protection
AC electrical meter EN 50470-1 and EN 50470-3 (MID European standards)
Overcurrent protection MCB class C
Safety protection RCD type B
