Raption
34
Instruction Manual
F
Charging summary
The following image appears when EVs have finished charging or the session has been
interrupted by the user.
Depending on the kind of charging that it has been done either AC or DC, the HMI screen can
show different process information.
1
5
6
2
3
8
4
7
