Raption
12
Instruction Manual
2
A
Main features
• HMI: there is a TFT colour touch screen of 8 inches, is the interface between the Charge
Point and the user. Provides detailed information for starting and stopping the charge,
including information concerning the recharge that is in progress (charge state of the
battery, charging time remaining, etc).
• RFID: there is a radio frequency reader that allows user authentication to proceed with
the recharging of the electric vehicle. At the discretion of the facility operator, the user’s
recharge also can be allowed or denied.
• User Management: provides a database that associates users with one or more
identification cards, you can also assign consumption and charging logs.
• Beacons light: by a LED beacons located above connectors, it is indicated the charging
status of the socket/connector.
• Ethernet: the unit allows communicate using TCP / IP on an Ethernet network, giving
flexibility to the system operator and management of the Charge Point.
• Remote monitoring and control in real-time 3G/4G: it can be done a remote device
connection or make OCPP integrations thanks to the integrated modem. In addition, by
using a standard Web browser, you can access to the Charge Point to monitor the status of
recharge and even run a Start / Stop remote.
• Historic charge transactions: the system is able to generate charging process reports,
according to the historical database of the Charge Point.
• Energy metering: Integrated meter, independent for AC and DC, is measuring power and
energy consumed by the EV during a charge session.
• OCPP integration: OCPP is a communication protocol between the Charge Point and
management platforms (BackOffice) for comprehensive management of charging. This
integration allows, among other things, management and user authentication as well as a
variety of parameters to monitor during a recharge.
